Outside dimension (LxWxH) | 450x216x110 (mm) |
Weight (excluding outside box) | 2750g-3200g |
Number of inlet/outlet ports | 3 (pieces) on each side (total 6 pieces) |
Diameter of fiber cable | Φ8—Φ23 (mm) |
Capacity of FOSC | Bunchy: 6—96 (Cores) Ribbon: max. 216 (Cores) |
1. Scope of application:
This Installation Manual is suit for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation.
The scope of application is: aerial, underground, pipeline, handhole. The ambient temperature ranges from -40 to 65℃.
2. Packing situation:
Model number | Big box size (CM) | Qty | Weight (KG) | Remarks |
GJS-E | 66.5*47*50 | Pack of 10 | 33 |
|
