| Outside dimension (LxWxH) | 410x200x120(mm) |
| Weight (excluding outside box) | 1900g-2100g |
| Number of inlet/outlet ports | 6 ports |
| Diameter of fiber cable | Φ8—Φ16(mm) |
| Capacity of FOSC | Bunchy: 6—96(Cores) Ribbon: max. 144 (Cores) |
1. Scope of application:
This Installation Manual is suit for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation.
The scope of application is: aerial, underground, wall-mounting, wall-mounting in duct and handhole. The ambient temperature ranges from -40 to +65℃.
2. Packing situation:
| Model number | Big box size (CM) | Qty | Weight (KG) | Remarks |
| GJS-A | 66.5*43*43 | Pack of 10 | 24.7 |
|
