| Outside dimension (LxWxH) | 280x200x90 (mm) |
| Weight (excluding outside box) | 1200g-1500g |
| Number of inlet/outlet ports | max. 4 pieces |
| Diameter of fiber cable | Φ8—Φ14 (mm) |
| Capacity of FOSC | Bunchy: 6—96 (Cores) |
1. Scope of application:
This Installation Manual suits for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation.
The scope of application is: aerial and wall-mounting. The ambient temperature ranges from -40 to 65℃.
2. Packing situation:
| Model number | Big box size (CM) | Qty | Weight (KG) | Remarks |
| GJS-M | 56*42*31 | Pack of 10 | 12.5 |
|
